PDR rework systems, launch of its latest innovation – the IR-Q3 Semi-Automatic Assisted Rework System. Designed to meet the growing demands of modern electronics manufacturing, the IR-Q3 combines cutting-edge infrared heating technology with advanced automation to deliver exceptional performance, accuracy, and ease of use.
The PDR IR-Q3 sets a new benchmark in rework technology, offering focused IR component heating, automated component removal and placement, and closed-loop non-contact temperature sensing. With its precision component handling – accurate to within 5 microns – and a reflow process observation camera, operators gain complete control and visibility throughout every stage of the rework process.
Engineered for high-reliability applications such as aerospace, automotive, and medical electronics, the IR-Q3’s feature-rich design includes:
- Three-zone quartz IR PCB preheating for optimal heat distribution
- Split beam prism alignment system enabling simultaneous PCB and component viewing
- Advanced thermal process control via PDR’s ThermoActive software, compatible with Windows 10+
- Precision pick-and-place capability for components as small as 2mm
- Reworkable area up to 254 x 406mm, accommodating a wide range of board sizes
“The IR-Q3 represents a major leap forward in semi-automated rework,” said Roger Gibbs, Managing Director at PDR. “It empowers engineers with the accuracy, control, and repeatability they need to rework today’s most complex electronic assemblies.”
Weighing in at just 75kg and requiring only a standard 208–240V power source, the IR-Q3 is designed to integrate seamlessly into modern production environments. Its modular accessory range – from precision lens attachments to reballing kits – ensures that it can be tailored to the specific needs of each user.
